Description
Plaon-convex cylindrical lenses are used to provide focusing power in one section only, For illumination or detection of light from line sources.Also used for anamorphic compression of beams and images.
Plano Convex Cylindrical Lens Specification:
|
Material: |
Fused Silica,BK7 or other optical glass |
|
Dimension Tolerance: |
+0.0, -0.1mm |
|
Center Thickness Tolerance: |
±0.1mm |
|
Paraxial Focal Length: |
±2% |
|
Surface quality: |
60/40 |
|
Clear Aperture: |
>85% |
|
Surface Figure: |
λ/4 @633nm |
|
Centration: |
3 arc minutes |
|
Bevel: |
<0.25mm×45° |
|
Coating: |
Upon requirement |
